Online PV-Elite Training


COURSE FEATURES

  • Free Training 1 Days
  • Login Days 30 Days
  • Validity 6 Months
  • Class Time Any Time
  • Support 24/7
  • Volume 10
  • Tools 1000
  • Commands 250
  • Exercise Dwg 75
  • Project 1
ENROLL THIS COURSE

Online Pressure Vessel Design Course

PV Elite provides engineers, designers, estimators, fabricators and inspectors around the world with solutions that match their pressure vessel and heat exchanger design needs. Because the program is easy to learn and use, it is perfect for both regular and occasional users requiring fast start up and confidence in their safety code calculations. PV Elite is a complete solution for the quick and intuitive design of new pressure vessels, and it also evaluates and re-rates existing vessels, including Fitness for Service analysis. The program considers the whole vessel, addressing all of the wall thickness rules and stress analysis requirements for vertical towers, horizontal vessels and heat exchangers. Also, individual vessel components may be evaluated.

PV Elite performs calculations in accordance with ASME Section VIII, Divisions 1 & 2, PD 5500, and EN 13445. Rules from API 579 (Fitness for Service) are also included for evaluating the current state and remaining life of existing vessels. Outputs and Reports To simplify inspection requirements, PV Elite lists the most important equations such as required thickness and maximum allowable working pressure (MAWP) and also groups results by type (e.g. internal pressure, external pressure, bending stress, nozzles and flanges). Overall results are summarized where the element or detail controlling the overall vessel MAWP is identified..

Data Collection PV Elite makes defining pressure boundary conditions for vessels and exchangers easy, even for load sets that require significant data input. PV Elite streamlines data entry by breaking the input down into sensible subsets. Help on any input item is only a keystroke away. Graphics PV Elite's graphical representation of analysis models helps ensure confidence in the input and results. With PV Elite, analysis models can be viewed and manipulated with complete ease.

Who Should Attend PV Design Course

BE & Diploma Engineers, cad drafts man's, Mechanical engineering students, senior designers, maintenance, quality assurance, inspection and manufacturing personnel who work with oil & gas piping (e.g., in the chemical, petroleum, plastic processing, power, pulp and paper fields) will find it a time-saving means to broaden and update their knowledge of piping.

PV Design Course Syllabus

  • Introduction to Pressure Equipments in Process Industries
  • Pressure Vessel, Column and Reactors Design
  • Shell & Tube Heat Exchanger Design
  • Code Calc and Job Nature in EPC Companies
  • Component Design & Evaluation

PV Design Training Scope

  • Oil and &Gas, Petrochemical, Refinery, EPC
  • Power Plant & Energy Sectors
  • Refineries, Petro-chemical,Process Plants (Pharmacy, Paper, Tyre, Sugar),Process and Plant Design
  • Pharmaceutical, Water Treatment, Building Services, Shipbuilding and Architectural
  • Chemical, Power,Offshore,Food, Beverage, Brewing,
